ADVENTURER TWO
Description
When the task at hand calls for more muscle, this big brother of the Hauler is exactly what you need. It’s outfitted with an 800-pound payload capacity, beefed-up transaxle, four wheel drum brakes, and a reputation for being able to take on pretty much anything. Whether you’re moving supplies out to the back nine, or just want to show off a bit, this crew member is the boss.
Key Parameters
Detailed Parameters
| Official Web | www.yamahagolfcar.com |
| Maker | YAMAHA |
| Golfcart Type | BUSINESS TRANSPORT |
| Model | ADVENTURER TWO |
| Year | |
| Frame | HybriCore™ Chassis features a robotic welded automotive ladder-style steel frame mated to a polypropylene structural floor. Frame is protected with a multi-step full-immersion phosphate treatment, electro-deposition epoxy-based coating, and an electrostat |
| Body &Finish | Custom-formulated thermoplastic olefin and the front is painted with a two-part top coat of high-luster automotive-grade polyurethane. |
| Front Body&Finish | |
| Rear Body & Finish | |
| Chassis | |
| Overall Length | 2922 mm (115 in) |
| Overall Width | 1243 mm (48.9 in) |
| Overall Height | |
| Overall Height(no canopy) | |
| Overall Height(with canopy) | |
| Wheel Base | 1200 mm (47.2 in) |
| Front Wheel Track | 990 mm (39 in) |
| Rear Wheel Track | 980 mm (38.6 in) |
| Ground Clearance(at differential) | Electric: 109 mm (4.2 in) Gas: 115 mm (4.5 in) |
| Power Source | |
| Valve Train | |
| Motor Type | SINGLE CYLINDER 60° INLCINE OHV |
| Cylinders | |
| Continuous Horsepower | |
| Intermittent Horsepower | |
| Horsepower(KW) | |
| Fuel System | |
| Electric System | |
| Batteries(qty/type) | |
| Key or Pedal | |
| Battery Charger | |
| Speed Controller | |
| Oil Capacity | |
| Fuel Capacity | 22 liters (5.8 U.S. gal) |
| Maximum Torque | |
| Seating Capacity | 2 persons |
| Hill Climbing Capacity | 20° |
| Minimum Turning Radius | 2.8 m (9.2 ft) |
| Vehicle Capacity | |
| Dry Weight Less Batteries | |
| Dry Weight(without batteries) | Gas: 392 kg (864.2 lbs) |
| Curb Weight | |
| Outside Clearance Circle | |
| Speed - High (Level Ground) | |
| Speed - Low (Level Ground) | |
| Speed Range | |
| Forward Speed (Level Ground) | |
| Reverse Speed (Level Ground) | |
| Ground Speed (level ground) | |
| Turning Radius | |
| Steering | Self-compensating single reduction helical rack-and-pinion, permanently lubricated with sealed, greaseless tie-rod ends |
| Suspension | |
| Service Brake | |
| Brakes | |
| Brake Stopping Distance | |
| Parking Brake | |
| Seating | |
| Battery Charging Time | |
| Running Kilometer |
