TXT
Description
REFINED TO A TEE
The E-Z-GO® TXT® golf car combines proven reliability with the industry’s latest innovations to deliver a consistently smoother ride and greater energy efficiency. Featuring a 48-volt electric drivetrain and TruCourse™ Technology, it offers the perfect balance of performance and efficiency to your course.
Key Parameters
Detailed Parameters
| Official Web | www.ezgo.com |
| Maker | EZGO |
| Golfcart Type | FLEET GOLF |
| Model | TXT |
| Year | |
| Frame | |
| Body &Finish | |
| Front Body&Finish | Injection-molded TPO |
| Rear Body & Finish | Injection-molded TPO |
| Chassis | |
| Overall Length | 93.0 in (236 cm) |
| Overall Width | 47.0 in (119 cm) |
| Overall Height | |
| Overall Height(no canopy) | 46.5 in (118 cm) (top of steering wheel) |
| Overall Height(with canopy) | 67.5 in (171 cm) (top of sun canopy) |
| Wheel Base | 66.0 in (168 cm) |
| Front Wheel Track | 34.0 in (86 cm) |
| Rear Wheel Track | 38.5 in (97 cm) |
| Ground Clearance(at differential) | 4.25 in (10.8 cm) |
| Power Source | 4-Cycle 24.5 cu in (401 cc) low-emissions |
| Valve Train | |
| Motor Type | |
| Cylinders | |
| Continuous Horsepower | |
| Intermittent Horsepower | |
| Horsepower(KW) | 13.5 hp (10.1 kW) exceeds SAE J1940 Std. |
| Fuel System | |
| Electric System | Starter/Generator, Solid-State Regulator |
| Batteries(qty/type) | One, 12-volt maintenance-free |
| Key or Pedal | Pedal |
| Battery Charger | |
| Speed Controller | |
| Oil Capacity | |
| Fuel Capacity | 5.3 gallon (20.0 L) tank |
| Maximum Torque | |
| Seating Capacity | 2-person |
| Hill Climbing Capacity | |
| Minimum Turning Radius | |
| Vehicle Capacity | |
| Dry Weight Less Batteries | |
| Dry Weight(without batteries) | 760 lb (344 kg) |
| Curb Weight | 780 lb (354 kg) |
| Outside Clearance Circle | |
| Speed - High (Level Ground) | |
| Speed - Low (Level Ground) | |
| Speed Range | |
| Forward Speed (Level Ground) | |
| Reverse Speed (Level Ground) | |
| Ground Speed (level ground) | 13 mph +/- 0.5 mph (21 kph +/- 0.8 kph) |
| Turning Radius | |
| Steering | Self-compensating rack and pinion |
| Suspension | |
| Service Brake | Rear wheel mechanical self-adjusting drum |
| Brakes | |
| Brake Stopping Distance | |
| Parking Brake | Self-compensating single-point engagement |
| Seating | |
| Battery Charging Time | |
| Running Kilometer |
