HAULER® 1200x Gas
Description
Your work is unforgiving. Let the Hauler® 1200 help carry the load. With a customizable bed and practical dash design, it's ready to transport the tools and equipment every job needs.
Key Parameters
Detailed Parameters
| Official Web | www.ezgo.com |
| Maker | EZGO |
| Golfcart Type | BUSINESS TRANSPORT |
| Model | HAULER® 1200x Gas |
| Year | |
| Frame | Welded Steel with Durashield™ Powder Coat |
| Body &Finish | |
| Front Body&Finish | Injection-Molded TPO, Painted |
| Rear Body & Finish | Injection-Molded TPO, |
| Chassis | |
| Overall Length | 119.0 in (303 cm) |
| Overall Width | 49.4 in (125 cm) |
| Overall Height | |
| Overall Height(no canopy) | 53.0 in (135 cm) (Top of steering wheel |
| Overall Height(with canopy) | 77.0 in (196 cm) |
| Wheel Base | 77.5 in (197 cm) |
| Front Wheel Track | 38.0 in (97 cm) |
| Rear Wheel Track | 38.5 in (98 cm) |
| Ground Clearance(at differential) | 7.0 in (18 cm) |
| Power Source | |
| Valve Train | |
| Motor Type | |
| Cylinders | |
| Continuous Horsepower | |
| Intermittent Horsepower | |
| Horsepower(KW) | 13.5 hp (10.1 kW) Exceeds SAE J1940 Std. |
| Fuel System | |
| Electric System | Starter/Generator. Solid State Regulator |
| Batteries(qty/type) | One, 12 Volt Maintenance Free |
| Key or Pedal | Pedal |
| Battery Charger | |
| Speed Controller | |
| Oil Capacity | |
| Fuel Capacity | 6.0 Gallon (22.7 L) tank |
| Maximum Torque | |
| Seating Capacity | 2 Person |
| Hill Climbing Capacity | |
| Minimum Turning Radius | |
| Vehicle Capacity | |
| Dry Weight Less Batteries | |
| Dry Weight(without batteries) | 963 lb (437 kg) (Without Batteries) |
| Curb Weight | 1003 lb (455 kg) |
| Outside Clearance Circle | 23.5 ft (7.16 m) |
| Speed - High (Level Ground) | |
| Speed - Low (Level Ground) | |
| Speed Range | |
| Forward Speed (Level Ground) | |
| Reverse Speed (Level Ground) | |
| Ground Speed (level ground) | 16.5 mph ± 0.5 mph (26.58 kph ± 0.8 kph) |
| Turning Radius | |
| Steering | Self-Compensating Rack and Pinion |
| Suspension | |
| Service Brake | Rear Wheel Mechanical Self-Adjusting Drum |
| Brakes | |
| Brake Stopping Distance | |
| Parking Brake | Self-Compensating, Single Point Engagement |
| Seating | |
| Battery Charging Time | |
| Running Kilometer |
