HAULER® PRO X
Description
UTILITY
Maintaining a pristine course isn't always a pretty job. And when it's time to do the heavy hauling, these vehicles are ready to work. From big beds and payloads to features that help you get more done, Cushman® utility vehicles were made to get your course ready for play.
Key Parameters
Detailed Parameters
| Official Web | www.ezgo.com |
| Maker | EZGO |
| Golfcart Type | BUSINESS TRANSPORT |
| Model | HAULER® PRO X |
| Year | 0 |
| Frame | Welded Steel Durashield™ Powder Coat |
| Body &Finish | |
| Front Body&Finish | Injection Molded TPO |
| Rear Body & Finish | Injection Molded TPO |
| Frame Chassis | |
| Overall Lenghth | 119 in (302.26 cm) |
| Overall Width | 49.4 in (126 cm) |
| Overall Height | |
| Overall Height(no canopy) | |
| Overall Height(with canopy) | 53.0 in (135 cm) (Top of steering wheel) |
| Intersecting Aisle | |
| Wheel Base | |
| Front Wheel Track | 38.0 in (97 cm) |
| Rear Wheel Track | 38.5 in (98 cm) |
| Ground Clearance(at differential) | 7.0 in (18 cm) |
| Power Source | 72-Volts DC |
| RPMs | |
| Shunt Wound | |
| Output Rating | |
| Motor Control Unit | |
| Continuous Horsepower | |
| Intermittent Horsepower | |
| Horsepower(KW) | 22.4HP (16.7 kW) - Measured at Peak Torque |
| Electric System | 72 Volt |
| Batteries(qty/type) | Nine, 8-Volt Deep Cycle |
| key or Pedal Start | |
| Battery Charger | 900 Watt 72V DC |
| Speed Controller | 350 Amp AC |
| Drive Train | Motor Shaft Direct Drive |
| Transaxle | Differential with Helical Gears |
| Gear Selection | |
| Rear Axle Ratio | 17:01 |
| Seating Capacity | 2 Persons - Bench |
| Transmission | |
| Seating Capacity and Style | |
| Total Vehicle Capacity | |
| Dry Weight(without batteries) | 948 lb (430 kg) (Without Batteries) |
| Dry Weight(With Batteries) | |
| Curb Weight>(w/ Batteries) | |
| Curb Weight | 1513 lb (686.29 kg) |
| Vehicle Load Capacity | 900 lb (408 kg) |
| Outside Clearance Circle | 24.0 ft (7.3 m) |
| Ground Speed (level ground) | 16.5 mph +/- 0.5 mph (27 kph +/-0.8 kph) |
| Forward Speed (level ground) | |
| Reverse Speed (level ground) | |
| Programmable Speed Range | |
| Max Torque | |
| Speed Range | |
| Maximum Forward Speed | |
| Fuel Consumption On Flat Paved Road | |
| Hill Climbing Capacity | |
| Minimum Turning Radius | |
| Towing Capacity | 1200 lb (544.31 kg) max load |
| Steering | Self-compensating Rack and Pinion |
| Brakes | |
| Service Brake | Rear Wheel Mechanical Self-adjusting Drum |
| Parking Brake | Self-compensating, Single Point Engagement |
| Battery charging time | |
| Running Kilometers |
